| Rating |
4.5 to 5.5 VDC |
| Weight (approx.) |
350g |
| Magnet Disc Dimension (approx.) |
15Φ x79Φx 4T mm |
| Ring Dimension (approx.) |
35.3Φ x 45Φ x 62.5L mm |
| Output Cable Length |
525 +20/-10 mm (EM5 connector is not included) |
| Connector Type |
EM5 5-pin male plug-and-turn metal connector with a Yellow or White Tag #1 |
| Connector IP Rating |
IPx6 |
| Color of Plastic Housing |
Black (plastic housing only) |
| Type of Hall Sensor |
Double hall sensors |
| Number of Magnetic Sensors |
12 magnets |
| Speed Sensor Mounting Direction |
Mounting from passenger side to driver side via BB |
| Speed Sensor IP Rating |
IPx5 |
| Operating Temperature |
-20℃ to 45℃ |
| Storage Temperature/ Humidity |
0℃ to 40℃ / < Humidity 65%@25C |
| Standards Compliance |
CE/FCC, ISO13849-1:2015,
EN15194: 2017 |
